تابلو و توزیع برق
/
پشتیبان گیری مواد
/
شکستن مدار برای ترانسفورماتور، ژنراتور و حفاظت از سیستم
/
3VA6440-6JQ41-2AA0
وضعیت
:
موجود در انبار اروپا - زمان تحویل 4 تا 6 هفته
برند
:
Siemens
تایپ کالا
:
3VA6440-6JQ41-2AA0
کد سازنده
:
3VA64406JQ412AA0
کد EAN
:
4042948863497
ویژگیها
Suitable for Hutch rail assembly
No
Integrated ground closure protection
Yes
Number of help contacts as changers
0
Position of connection for main circuit
other
Engine drive integrated
No
Set range of short-term delayed short-circuit trigger
240... 4,000 A
قیمت
:
استعلام
حداقل قابل خرید
:
1 عدد
قابل پرداخت
:
استعلام
مشاهده جزییات فنی کالا :
3VA2163-6HL32-0JL0, power switch 3VA2 IEC Frame 160 switching power class H Icu = 85kA @ 415V 3-pole, system protection ETU320, LI, In = 63A overload protection Ir = 25A... 63A Short
DEK 6 FWZ 41-50, clamp marking, white, grid in mm: 6.00, printed characters: numbers, horizontal, width: 6 mm, height: 5 mm
3VA1225-6GF42-0CA0, power switch 3VA1 IEC Frame 250 switching power class H Icu = 70kA @ 415V 4-pole, system protection TM240, ATAM, In = 250A overload protection Ir = 175A... 250A
3VA2510-5HN32-0KC0, power switch 3VA2 IEC Frame 1000 switching power class M Icu = 55kA @ 415V 3-pole, system protection ETU350, LSI, In = 1000A overload protection Ir = 400A... 100
Circuit breaker 3VA6 UL Frame 600 switching power class H 65kA @ 480V 4-pole
Circuit breaker 3VA6 UL Frame 600 switching power class H 65kA @ 480V 4-pole, system protection ETU560, LSIG, In = 400A overload protection, 100% rated Ir = 160A... 400A short circuit protection Isd = 0,6.. 10x In, Ii = 1,5.. 12x In N- conductor protection adjustable (OFF, up to 160%) Earth-connection protection Ig = 0,2... 1 x In = tg = 0,05- 0,8s without connection to compact power switch SENT- for short-circuit protection and control in the case of the system. The 3VA5 and 3VA6 compact power switches set standards in flexibility and modular variety with low space requirements. In addition to the IEC standard, the two series also meet the UL standard. All functionalities can therefore be used and used for plants worldwide. The 3VA6 compact power switches are available in 3 and 4-pole version with different continuous current for assembly in fixed installation as well as in plug-in / push-in technology. The modular and easy-to-install accessories with a wide range of functions are consistent and consistent for all sizes and series of compact power switches 3VA. SENTRON Compact power switch 3VA - A system. For all applications.
شما هم می توانید دیدگاه خود را درباره این کالا ثبت کنید.
دیدگاه خود را ثبت کنید
3VA6440-6JQ41-2AA0, power switch 3VA6 UL Frame 600 switching power class H 65kA @ 480V 4-pole
