وضعیت
:
موجود در انبار اروپا - زمان تحویل 4 تا 6 هفته
برند
:
Siemens
تایپ کالا
:
8WH6000-0AH00
کد سازنده
:
8WH60000AH00
کد EAN
:
4001869471471
ویژگیها
Connectable cross-section
0.5... 10 mm ²
Number of terminals per floor
2
Internal closed floors
No
Type of assembly
Hutschiene TH35
Flammable class of the insulating material according to UL94
V0
Operating temperature
-60... 105 ° C
قیمت
:
استعلام
حداقل قابل خرید
:
1 عدد
قابل پرداخت
:
استعلام
مشاهده جزییات فنی کالا :
PXL-C10 / 2-DC, line protection switch, 10 A, 2p, characteristic: C, DC
3VA1220-6EF42-0AE0, power switch 3VA1 IEC Frame 250 switching power class H Icu = 70kA @ 415V 4-pole, system protection TM240, ATAM, In = 200A overload protection Ir = 140A... 200A
3VA1220-4EF32-0AH0, power switch 3VA1 IEC Frame 250 switching power class S Icu = 36kA @ 415V 3-pole, system protection TM240, ATAM, In = 200A overload protection Ir = 140A... 200A
RKi 4 / 18 SL-18x4 ², row clamp housing, protection type IP54 / IP66, max. Lead cross section 4 ², impact resistance IK08, protection class II, Ui 400V AC, halogen-free
IPO- technology, 6mm2 width 8,2mm, grey 1000V 2 closing points
Clamp, ipo connection, passage terminal, 6mm ², grey line terminal connection technology for various industrial applications and modern building installation by Siemens. Whether you choose the screw, pull, push or fast connection: All connection techniques can be freely combined. The label and test accessories are standardized and can be used across borders. With the SIEMENS series clamps, many applications in industry, purpose and housing can be realized. So you have the right connection technology for each connection. The Siemens line clamps are particularly distinguished by: 1. Permanent safe contact. 2. Easy to connect electrical connections such as cables and lines. 3. Implementation of a variety of applications. 4. Comfortable and simple assembly and connection technology. 5. Extensive and standardized accessories. 6. Reliable safety during installation thanks to standard contact protection. 7. Optimal technology for your safety - only from Siemens.
شما هم می توانید دیدگاه خود را درباره این کالا ثبت کنید.
دیدگاه خود را ثبت کنید
8WH6000-0AH00, transmission terminal IPO technology, 6mm2 width 8,2mm, grey 1000V 2 closing points
