51 2403 RFLOU, LED external light VIA 53W 8340lm IP66 asym- broadstr 3000K Ra? 70 Ta -40 ° C / + 40 ° C L90 > 100000 h (@ Ta max) Ready for Light Management Systems (RFL) 001184

LED external light VIA 53W 8340lm IP66 asym- broadstr 3000K Ra? 70 Ta -40 ° C / + 40 ° C L90 > 100000 h (@ Ta max) Ready for Light Management Systems (RFL) 001184

LED external light, VIA, 53 W, 8340 lm, SKII, IP66, asymmetric wide-beam, 3000 K, Ra? 70, Ta -40 ° C / + 40 ° C, L90 > 100000 h (@ Ta max), Ready for Light Management Systems (RFL), Socket top and bottom (RFLOU), Disc safety glass clear, case aluminium pressure cast, lacquered, color grey, DB 702, EAN / GTIN: 40412376714. of the product range of outstanding green LED. Two-piece powder-coated aluminium die-cast housing, foldable, with fuse bar. LED module (s) and EVG mounted on non-removable support sheets in the housing top. Cable introduction with connection and strain load, separation connection and pressure balancing system in the housing body, flat safety glass, silicone seal, central aluminium cap. Zhaga-compliant LED modules with highly efficient optics, direct-radiant, multi-layer technology. EVG with high shock voltage resistance, overload and short circuit protection. Universal, aluminium pressure-cast mast for 60 / 76 mast or mast mounting. For mast 42, separate reduction accessories are required. Anchor adjustment 0 °, 5 °, 10 °, 15 ° for mounting, 0 °, -5 °, -10 °, -15 ° for mounting, scaling on the lamp housing. The lamp is prepared for the subsequent use of components of a light management system with Zhaga-compliant socket connection. RFLs of shoe use without exception D4i operating equipment. All D4i-Zhaga-book-18-certified controllers and D4i-Zhaga-book-18-certified sensors available on the market can be used in combination with RFLs from Schuch. However, the functionality of the lamps and components may be limited by controllers and sensors that do not meet the D4i standard. In addition, in the case of such uncertified components, there may be damage to both the lamps and the components.
