D63IDK1S0, shear, exhaust / reair operation, EEK: A, Touch C

Design: Sneak-dining-design wall mounting glass disc: black printed Optional exhaust or transformer air operation For air-to-air operation a standard air-to-air set (special accessories) is required Main features: capacitor engine workstation lighting with 2 x 3 W colour temperature: 4000 K illumination: 127 lux 1 metal fat filter comfort functions: electronic control via TouchControl, background light 3 power levels and 1 intensive level automatic reset of intensive to normal level after 5 min. Satisfaction display for fat and odour filter comfort during cleaning: large opening angle of the glass plate with locking function for easy filter access and easy cleaning. The surfaces and materials are smooth and easy to clean. Metal fat filter, dishwasher-suitable power exhaust air: according to EN 61591 and EN / IEC 60704-2-13 your device can achieve the following values in exhaust air: power level 1: fan power: 220 m3 / h; noise value 46 dB (A) re1pW power level 2: fan power: 315 m3 / h; noise value 53 dB (A) re1pW power level 3: fan power: 430 m3 / h; noise value 60 dB (A) re1pW intensive level 1: fan power: 550 m3 / h; Noise value 65 dB (A) re1pW Energy efficiency class: A (on an energy efficiency class scale of A + + + to D) Average energy consumption: 43.8 kWh / year * fan efficiency class: A * lighting efficiency class: A * fat filter efficiency class: E * power conversion: according to EN 61591 and EN / IEC 60704-2-13, your device can achieve the following values in air operation with the standard air set (available as optional accessories): 1: fan power / 215 m3; noise value 51 dB (A) re1pW power level 2: fan power 300 m3 / h; noise value 61 dB (A) re1pW power level 3: fan power 445 m3 / h; noise value 69 dB (A) re1pW intensity level 1: fan power 550 m3 / h; Noise value 72 dB (A) re1pW Technical data and sustainability: Information on consumption: Total connection value: 223 W Voltage: 220 - 240 V Information on planning and installation: Device dimensions Exhaust air (HxBxT): 690-900 x 590 x 325 mm Exhaust air (HxBxT): 720-975 x 590 x 325 mm Exhaust air connections ± 150 mm Length connection cable: 1.5 m with plug delivery with damper damper
